系統組裝週邊配件
本頁最新更新日期: 2023年12月07日


..........................................................................................................................................................................................................................................................................................

4SATA-1MSAS-500MM

Four SATA (Host) to SFF-8087 Mini-SAS (Device) cable
*
4條SATA (Host控制端)至1條SFF-8087 Mini-SAS 6G (Device裝置端)
* 適用於RAID卡或主機板端為SATA介面, 熱插拔背板端為SFF-8087 Mini-SAS介面
* 線長440mm, 總長500mm (含兩端接頭)
* 台灣工控全球品質保證及保固3年

* 簡稱41, 或者反向線

..........................................................................................................................................................................................................................................................................................

1MSAS-4SATA-500MM

SFF-8087 Mini-SAS (Host) to Four SATA (Device) cable
*
1條SFF-8087 Mini-SAS 6G (Host控制端)至4條SATA (Device裝置端)
* 適用於RAID卡或主機板端為SFF-8087 Mini-SAS介面, 熱插拔背板端或HDD為SATA介面
* 線長440mm, 總長500mm (含兩端接頭)
* 台灣工控全球品質保證及保固3年

* 簡稱14, 或者正向線

..........................................................................................................................................................................................................................................................................................

1MSAS-1MSAS-500MM

SFF-8087 Mini-SAS (Host) to Mini-SAS (Device) cable
*
1條SFF-8087 Mini-SAS 6G (Host控制端)至1條SFF-8087 Mini-SAS 6G (Device裝置端)
* 適用於RAID卡或主機板端為SFF-8087 Mini-SAS介面, 熱插拔背板端亦為SFF-8087 Mini-SAS介面
* 線長440mm, 總長500mm (含兩端接頭)
* 台灣工控全球品質保證及保固3年

* 簡稱11, 或者雙向線

..........................................................................................................................................................................................................................................................................................

SFF-8643-500MM

SFF-8643 Mini-SAS HD (Host) to SFF-8643 Mini-SAS HD (Device) cable
*
1條SFF-8643 Mini-SAS HD 12G (Host控制端)至1條SFF-8643 Mini-SAS HD 12G (Device裝置端)
* 適用於RAID卡或主機板端為SFF-8643 Mini-SAS HD介面, 熱插拔背板端亦為SFF-8643 Mini-SAS HD介面
* 線長440mm, 總長500mm (含兩端接頭)
* 台灣工控全球品質保證及保固3年

* 簡稱11, 或者雙向線

..........................................................................................................................................................................................................................................................................................

4SATA-SFF-8643-500MM

Four SATA (Host) to SFF-8643 Mini-SAS HD (Device) cable
*
4條SATA (Host控制端)至1條SFF-8643 Mini-SAS HD 12G (Device裝置端)
*
適用於RAID卡或主機板端為SATA介面, 熱插拔背板端為SFF-8643 Mini-SAS HD介面
*
線長440mm, 總長500mm (含兩端接頭)
* 台灣工控全球品質保證及保固3年

* 簡稱41, 或者反向線

..........................................................................................................................................................................................................................................................................................

SFF-8643-4SATA-500MM

SFF-8643 Mini-SAS HD (Host) to Four SATA (Device) cable
*
1條SFF-8643 Mini-SAS HD 12G (Host控制端)至4條SATA (Device裝置端)
*
適用於RAID卡或主機板端為SFF-8643 Mini-SAS HD介面, 熱插拔背板端或HDD為SATA介面
*
線長440mm, 總長500mm (含兩端接頭)
* 台灣工控全球品質保證及保固3年

* 簡稱14, 或者正向線

..........................................................................................................................................................................................................................................................................................

Male2.54-Female2.00

USB 2.0 Male2.54mm to Female2.00mm cable at 100mm
* USB 2.54mm公座轉2.00mm母座, 轉接線長100mm

* 轉接線使用場合: 周邊裝置為USB 2.54mm接頭, 主機板介面為USB 2.00mm時

* 線長: 100mm

..........................................................................................................................................................................................................................................................................................

USB3-USB2-P2.00mm

USB3 male to USB2 female pitch 2.00mm at 200mm cable
* USB 3.0 19pin公座轉USB 2.0 9pin的pitch 2.00mm母座, 轉接線長200mm

* 轉接線使用場合: 周邊裝置為USB 3.0接頭, 主機板介面為USB 2.0以及針腳間距2.00mm時

* 線長: 200mm

* 備註: 傳輸速率維持USB 2.0, 不是USB 3.0速度

..........................................................................................................................................................................................................................................................................................

USB3-USB2-P2.54mm

USB3 male to USB2 female pitch 2.54mm at 150mm cable
* USB 3.0 19pin公座轉USB 2.0 9pin的pitch 2.54mm母座, 轉接線長150mm

* 轉接線使用場合: 周邊裝置為USB 3.0接頭, 主機板介面為USB 2.0以及針腳間距2.54mm時

* 線長: 150mm

* 備註: 傳輸速率維持USB 2.0, 不是USB 3.0速度

..........................................................................................................................................................................................................................................................................................

USB3-USB2-P2.54mm-460

USB3 Female to USB2 female pitch 2.54mm at 460mm cable
* USB 3.0 19pin座轉USB 2.0 9pin的pitch 2.54mm母座, 轉接線長460mm

* 轉接線使用場合: 周邊裝置為USB 3.0接頭, 主機板介面為USB 2.0以及針腳間距2.54mm時

* 線長: 460mm

* 備註: 傳輸速率維持USB 2.0, 不是USB 3.0速度

..........................................................................................................................................................................................................................................................................................

U2-P2.54-U3-150MM

USB2 2.54mm male to USB3 female 150mm cable
* USB 2.0 pitch 2.54mm公座轉USB3.0 19pin母座, 轉接線長150mm

* 轉接線使用場合: 周邊裝置為USB 2.0針腳間距2.54mm母座接頭, 主機板介面為USB 3.0 19pin公座時

* 線長: 150mm

* 備註: 傳輸速率維持USB 2.0, 不是USB 3.0速度

..........................................................................................................................................................................................................................................................................................

L-BK-DB9-USB2.0-450MM

Nickel L bracket with DB9 Male to USB2.0 female pitch 2.00mm cable 450mm
* DB9公座全高型L型鍍鎳封口片

* USB 2.0母座及針腳間距2.00mm

* 線長: 450mm (線長不包含兩邊端子)

* 備註: USB 2.0母座及針腳間距若為2.54mm, 料號則為L-BK-DB9-USB2.0-450MM-2.54

* 備註: MOQ 100pcs

..........................................................................................................................................................................................................................................................................................

4TO8-150-ADAPTER

ATX12V 4-pin female to EPS12V 8-pin male adapter with 150mm
* ATX12V 4pin母座轉EPS12V 8pin公座
接頭

* 轉接線使用場合: 周邊裝置為ATX12V 4pin接頭, 主機板介面為EPS12V 8pin時

* 線長: 150mm

..........................................................................................................................................................................................................................................................................................

B4P-EPS8P-150MM

Molex 4pin Male to EPS12V 8pin Male adapter with 150mm
* 2組Molex大4pin公座轉1組EPS12V 8pin公座
接頭

* 轉接線使用場合: 周邊裝置為Molex大4pin母座接頭, 主機板介面為EPS12V 8pin母座時

* 線長: 150mm

..........................................................................................................................................................................................................................................................................................

Y-CABLE-20191024

3 pin Female Y-Splitter to Dual 3 pin Male x2-fan-250mm
* 1組3pin電源輸入母座
接頭轉2組3pin風扇輸出公座接頭

* 線長: 250mm

..........................................................................................................................................................................................................................................................................................

SATA-MALE-MOLEX-FEMALE-150MM

SATA 15pin Male to Molex 4pin Female adapter with 150mm
* 1組SATA15pin電源輸入公座
接頭轉1組Molex大4P電源輸出母座接頭

* 線長: 150mm

..........................................................................................................................................................................................................................................................................................

24TO20-150exted


SSI 24pin Male to ATX12V 20pin Female converter
* SSI 24pin公座轉ATX12V 20pin母座轉接線
* 線長100mm~200mm之間
* 適用於電源
的24pin轉換至主機板的20pin

..........................................................................................................................................................................................................................................................................................

20TO24-150EXTEND

ATX12V 20pin Male to SSI 24pin Female converter
* ATX12V 20pin公座轉SSI 24pin母座轉接線
* 線長100mm~200mm之間
* 適用於電源
的20pin轉換至主機板的24pin

..........................................................................................................................................................................................................................................................................................

24TO24-300exted


SSI 24pin 300mm extension
* SSI 24pin母座轉公座延長線
* 線長300mm
* 適用於
系統內24pin線長不足之狀況下可使用

..........................................................................................................................................................................................................................................................................................

4TO4-300exted


ATX12V 4pin 300mm extension
* ATX 12V 4pin母座轉公座延長線
* 線長300mm
* 適用於
系統內ATX12V 4pin線長不足之狀況下可使用

..........................................................................................................................................................................................................................................................................................

8TO8-150exted


EPS 8pin to EPS 8pin 150mm extension
* EPS 12V 8pin母座轉公座延長線
* 線長150mm
* 適用於
系統內EPS12V 8pin線長不足之狀況下可使用

..........................................................................................................................................................................................................................................................................................

CLKF656


SATA to SATA Slim ODD adapter
*
筆記型光碟機端介面: slim SATA (7pin+6pin)
* 橋接主機板端介面: 小4pin電源輸入, SATA 7pin資料傳輸port

..........................................................................................................................................................................................................................................................................................

LKF248


Slim ODD SATA2 adapter
* 傳統Slim CD-ROM/DVD/DVD-RW介面可轉接至主機板之標準SATAII port
* 附2顆M2螺絲

..........................................................................................................................................................................................................................................................................................

JMRER1


Slim ODD IDE adapter
* 傳統Slim CD-ROM/DVD/DVD-RW介面可轉接至主機板之標準IDE port
* 附2顆M2螺絲
* 尺寸圖面說明

..........................................................................................................................................................................................................................................................................................

JM215


Micro FDD adapter with electronic cable
*
尺寸圖面說明

..........................................................................................................................................................................................................................................................................................

2525TO3HDBK

2組5.25吋空間轉3顆3.5吋支架
* 2組5.25吋磁碟架空間可轉換安裝成3組3.5吋HDD
* 每套單位: 雙

..........................................................................................................................................................................................................................................................................................

3525TO5HDBK


3組5.25吋空間轉5顆3.5吋支架
* 3組5.25吋磁碟架空間可轉換安裝成5組3.5吋HDD
* 每套單位: 雙

* 設計更新日期: 2014年12月03日

..........................................................................................................................................................................................................................................................................................

25-35-BK


5.25" 3.5" 2.5" 多功能HDD轉換支架
* 獨特設計,1個5.25"光碟機空間內可相容安裝1顆3.5"硬碟
* 或者1個3.5"硬碟空間內可相容安裝2顆2.5"硬碟
* (可相容2顆7mm高度之2.5"硬碟)
* (可相容2顆9.5mm高度之2.5"硬碟)
* (可相容2顆12.5mm高度之2.5"硬碟)
* (可相容1顆15mm高度之2.5"硬碟)
* 每套單位為雙,
安裝說明圖
*
零件包明細: 8顆圓頭M3螺絲‧4顆圓頭#6螺絲 (尺寸圖面說明)
